Περιγραφή
Digital Media Receiver featuring Digital Radio DAB+ / Front AUX & USB / DSP with DTA & 13-Band EQ.
DAB+ Tuner
DAB (Digital Audio Broadcasting) delivers crystal clear audio from your favourite FM stations as well as a broad range of digital-only stations ranging from news and talk, to classical and rock. Normally, DAB+ is delayed by a few seconds compared to the FM broadcast.
Enjoy both better quality and richer content with DAB+.
K2 Technology for Enhanced Digital Sound Quality
K2 is a JVC original technology that reproduces the original master sound by expanding the frequency range.
For example, K2 will expand the digital data of the audio CD recorded at 44.1kHz to 192 kHz. It is also possible to recreate the high-frequency range above 20kHz that is cut during the CD formatting.
Sound Optimilization
Time Alignment:
By selecting the speaker type and the distance to the centre of the listening position, the head unit will automatically adjust the timing of the sound output from each of the speakers so that the sound from each of the speakers will arrive exactly at the same time to the listening position.
Sound Lift:
Virtually manipulate the height of the speakers by adjusting the sound frequencies.
Volume Link EQ:
Volume Link EQ boosts specific frequencies in the audio signal to compensate for the impact of road noise. It boosts frequencies in the music that are affected by road noise.
Short Chassis
The reduced depth of the chassis contributes to a weight reduction and facilitates easier installation.
DAB+ Tuner
DAB (Digital Audio Broadcasting) delivers crystal clear audio from your favourite FM stations as well as a broad range of digital-only stations ranging from news and talk, to classical and rock. Normally, DAB+ is delayed by a few seconds compared to the FM broadcast.
Enjoy both better quality and richer content with DAB+.
K2 Technology for Enhanced Digital Sound Quality
K2 is a JVC original technology that reproduces the original master sound by expanding the frequency range.
For example, K2 will expand the digital data of the audio CD recorded at 44.1kHz to 192 kHz. It is also possible to recreate the high-frequency range above 20kHz that is cut during the CD formatting.
Sound Optimilization
Time Alignment:
By selecting the speaker type and the distance to the centre of the listening position, the head unit will automatically adjust the timing of the sound output from each of the speakers so that the sound from each of the speakers will arrive exactly at the same time to the listening position.
Sound Lift:
Virtually manipulate the height of the speakers by adjusting the sound frequencies.
Volume Link EQ:
Volume Link EQ boosts specific frequencies in the audio signal to compensate for the impact of road noise. It boosts frequencies in the music that are affected by road noise.
Short Chassis
The reduced depth of the chassis contributes to a weight reduction and facilitates easier installation.
Χαρακτηριστικά
Κατασκευαστής:
JVC
MP3 playback:
- Yes
Audio
Equalizer bands quantity:
- 13
Frequency range:
- 20 - 20000 Hz
Signal-to-Noise Ratio (SNR):
- 98 dB
Clock
Integrated clock:
- Yes
Design
Product colour:
- Black
Volume control:
- Rotary
Display
Built-in display:
- Yes
Display type:
- LCD
Sound synchronized illumination:
- Yes
Ergonomics
Dimmer:
- Yes
Headphones
Impedance:
- 4 Ω
Networking
Bluetooth profiles:
- A2DP, AVRCP, HFP, PBAP, SPP, SSP
Bluetooth version:
- 4.2
Performance
Audio output channels:
- 4.0 channels
DIN size:
- 1 DIN
Disc types supported:
- No
Removable front panel:
- Yes
Ports & interfaces
AUX in:
- Yes
AUX in ports:
- 1
Bluetooth:
- Yes
Bluetooth range:
- 10 m
ISO connector:
- Yes
Microphone in:
- Yes
USB connector type:
- USB Type-A
USB port:
- Yes
USB port position:
- Front
USB version:
- 2.0
Power
Maximum power per channel:
- 50 W
Output power:
- 200 W
Radio
Auto digital tuning:
- Yes
Automatic presetting:
- Yes
DAB tuner:
- DAB+
FM band range:
- 87.5 - 108 MHz
LW band range:
- 153 - 279 kHz
Preset stations quantity:
- 42
Strong station memory:
- Yes
Supported radio bands:
- DAB+, FM, LW, MW
Recorder
Line outputs (RCA):
- 2
Transmitter
USB ports quantity:
- 1
Weight & dimensions
Depth:
- 100 mm
Height:
- 53 mm
Weight:
- 600 g
Width:
- 182 mm
Wireless LAN features
Signal strength:
- 4 dBm
Multimedia
Audio formats supported:
- FLAC, LPCM, MP3, WAV, WMA
Equalizer:
- Yes
