Epson ELPDC13 document camera White 25.4 / 2.7 mm (1 / 2.7") CMOS USB 1.1 (V12H757040)
Χαρακτηριστικά
Κατασκευαστής:
Epson
Horizontal rotation angle:
- -90 - 90°
Vertical rotation angle:
- -90 - 90°
Audio
Built-in microphone:
- Y
Camera
Digital zoom:
- 16x
Image freeze:
- Y
Maximum frame rate:
- 30 fps
Photo effects:
- Black&White
White balance:
- Auto
Zoom capability:
- Y
Design
Cable lock slot:
- Y
Cable lock slot type:
- Kensington
Illumination:
- Y
Product colour:
- White
Display
Supported graphics resolutions:
- 1920 x 1080 (HD 1080)
Image sensor
Optical sensor size:
- 25.4 / 2.7 mm (1 / 2.7\")
Sensor type:
- CMOS
Internal I/O
Parallel connector:
- Y
Lens system
Shooting area (WxD):
- 297 x 420 mm
Logistics data
Pallet gross height:
- 5.04 m
Pallet gross length:
- 120 cm
Pallet gross width:
- 80 cm
Pallet height (UK):
- 5.04 m
Pallet length (UK):
- 120 cm
Pallet width (UK):
- 100 cm
Products per pallet:
- 66 pc(s)
Products per pallet (UK):
- 110 pc(s)
Products per pallet layer:
- 6 pc(s)
Products per pallet layer (UK):
- 10 pc(s)
Operational conditions
Operating relative humidity (H-H):
- 20 - 80%
Operating temperature (T-T):
- 5 - 35 °C
Other features
Mac compatibility:
- Y
Packaging content
AC adapter included:
- Y
Carrying case:
- Y
Manual:
- Y
Software CD:
- Y
Packaging data
Bundled software:
- Easy Interactive Tools, TWAIN driver for Epson Document Camera (for Windows)
Cables included:
- AC
Quantity per pack:
- 1 pc(s)
Performance
Auto focus:
- Y
Image viewer:
- Y
Interface:
- USB 1.1
Light exposure modes:
- Auto
Light source:
- LED
Ports & interfaces
DC-in jack:
- Y
USB connector type:
- USB Type-B
VGA (D-Sub) input ports:
- 1
VGA (D-Sub) output ports:
- 1
Power
AC input frequency:
- 50 - 60 Hz
AC input voltage:
- 100-240 V
Power consumption (standby):
- 0.5 W
Power consumption (typical):
- 13 W
Power supply type:
- AC
Storage
Card reader integrated:
- Y
Compatible memory cards:
- SD
Maximum memory card size:
- 32 GB
System requirements
Compatible operating systems:
- Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X, Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Mac operating systems supported:
- Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported:
- Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Technical details
Country of origin:
- Philippines
Display modes:
- Microscope
Document size (max):
- A3
Lamp type:
- LED
Output resolutions:
- SXGA (1280*1024)/XGA (1024*768)/WXGA 16:10 (1280*800)/WXGA 16:9 (1360*768)/1080p (1920*1080), 480p/720p/1080p
Special features:
- Auto focus, Freeze, Parallel video output, SD card viewer, Split screen, Zoom
Split screen:
- Y
Video
Image quality adjustment:
- Brightness, Contrast
Weight & dimensions
Depth:
- 317 mm
Height:
- 447 mm
Package depth:
- 445 mm
Package height:
- 180 mm
Package weight:
- 4.58 kg
Package width:
- 235 mm
Weight:
- 2.5 kg
Width:
- 270 mm
