Περιγραφή
Premium Thunderbolt™ 4 Docking Experience: ThinkPad Thunderbolt 4 Workstation Dock delivers reliable and consistent industry leading video, data and power connectivity; Maximize Your Productivity: Expand your horizon with versatile 8K display support or multiple 4K displays support, Upto 230W Power Delivery to Workstation, silent firmware upgrades, VPro/AMT support and transfer data at lightning fast 40Gbps.; The ThinkPad Thunderbolt 4 Workstation Dock is future-proof and fully loaded to take your productivity, efficiency and creativity to the peak.
Χαρακτηριστικά
Κατασκευαστής:
Lenovo
Certification:
- cULus, FCC, ICES, NOM
USB Power Delivery up to:
- 230 W
Audio
Built-in speaker(s):
- No
Back panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
- 4
Design
Cable lock slot:
- Yes
Cable lock slot type:
- Kensington
LED indicators:
- Yes
Product colour:
- Black, Red
Display
HD type:
- 8K Ultra HD
Ergonomics
VESA mounting:
- Yes
Logistics data
Harmonized System (HS) code:
- 84733020
Networking
Ethernet LAN:
- Yes
Ethernet LAN data rates:
- 10,100,1000 Mbit/s
Operational conditions
Operating relative humidity (H-H):
- 5 - 95%
Operating temperature (T-T):
- 0 - 40 °C
Packaging content
AC adapter included:
- Yes
Warranty card:
- Yes
Packaging data
Cables included:
- AC
Quantity per pack:
- 1 pc(s)
Performance
Data transfer rate:
- 40 Gbit/s
Number of displays supported:
- 4
Ports & interfaces
Combo headphone/mic port:
- Yes
Connectivity technology:
- Wired
DC-in jack:
- Yes
DisplayPort version:
- 1.4
DisplayPorts quantity:
- 2
Ethernet LAN (RJ-45) ports:
- 1
HDMI ports quantity:
- 1
HDMI version:
- 2.1
Host interface:
- Thunderbolt 4
Microphone in:
- No
Thunderbolt 4 ports quantity:
- 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:
- 1
USB Power Delivery:
- Yes
Power
Output current:
- 15 A
Output voltage:
- 20 V
Power consumption (max):
- 230 W
Power supply:
- 300 W
Processor
Maximum digital resolution:
- 7680 x 4320 pixels
Storage
Card reader integrated:
- No
System requirements
Windows operating systems supported:
- Windows 10
Video
Maximum refresh rate:
- 30 Hz
Weight & dimensions
Depth:
- 80 mm
Height:
- 30 mm
Package depth:
- 195 mm
Package height:
- 85 mm
Package weight:
- 1.9 kg
Package width:
- 270 mm
Weight:
- 450 g
Width:
- 220 mm
