Teltonika NETWORKS TSW040 8-Port PoE+ Switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black (TSW040000000)
Περιγραφή
The TSW040 is an unmanaged 8-port PoE+ switch by Teltonika, featuring eight RJ45 ports with a total power budget of 240 W, or up to 30 W per port. This compact and rugged 8-port switch also features a 2-pin power input and an integrated DIN rail for easy mounting, making it ideal for industrial applications. The TSW040 has a wide voltage range of 7-57 VDC and a PoE-out voltage range of 44-57 VDC.
Χαρακτηριστικά
Κατασκευαστής:
Teltonika
Data transmission
MAC address table:
- 2048 entries
Switching capacity:
- 20 Gbit/s
Design
Housing material:
- Aluminium
LED indicators:
- Link, Power, Status
Product colour:
- Black
Rack mounting:
- No
Stackable:
- No
Management features
Switch type:
- Unmanaged
Networking
10G support:
- No
Networking standards:
- IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Operational conditions
Operating relative humidity (H-H):
- 10 - 90%
Operating temperature (T-T):
- -40 - 75 °C
Packaging content
Quick start guide:
- Yes
Performance
Reset button:
- No
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity:
- 8
Basic switching RJ-45 Ethernet ports type:
- Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity:
- 8
Power
DC input voltage:
- 7 - 57 V
Power over Ethernet (PoE) voltage:
- 48 V
Power source:
- DC
Power supply included:
- No
Power over Ethernet (PoE)
Power over Ethernet (PoE):
- Yes
Power over Ethernet (PoE) ports quantity:
- 8
Power over Ethernet (PoE) power per port:
- 30 W
Power over Ethernet (PoE) type supported:
- Active PoE
Total Power over Ethernet (PoE) budget:
- 240 W
Weight & dimensions
Depth:
- 74.6 mm
Height:
- 41.2 mm
Weight:
- 280 g
Width:
- 113.1 mm
