The CHIEFTEC APEX presents an E-ATX chassis with full clean tempered glass on the front and side panels, including four pre-installed 120mm ARGB fans that provide impressive style and cooling.
APEX with 4 pre-installed rainbow ARGB fans connected to a control hub that allows for ARGB M/B sync and fan speed control.
The case is generous with space, offering support for GPUs up to 400 mm in length, CPU coolers up to 175mm in height, and radiator support up to 360mm on the top and up to 420mm on the front.
CHIEFTEC APEX AIR is ready to bring more airflow and better cooling to modern gaming systems.
APEX with 4 pre-installed rainbow ARGB fans connected to a control hub that allows for ARGB M/B sync and fan speed control.
The case is generous with space, offering support for GPUs up to 400 mm in length, CPU coolers up to 175mm in height, and radiator support up to 360mm on the top and up to 420mm on the front.
CHIEFTEC APEX AIR is ready to bring more airflow and better cooling to modern gaming systems.
Χαρακτηριστικά
Κατασκευαστής:
Chieftec
Material:
- SPCC
Type:
- PC
Back panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
- 0
Cooling
Bottom fans diameters supported:
- 120 mm
Front fans diameters supported:
- 120,140 mm
Front fans installed:
- 3x 120 mm
Front radiator sizes supported:
- 240,280,360,420 mm
Liquid cooling capability:
- Yes
Liquid cooling installed:
- No
Number of bottom fans supported (max):
- 2
Number of front fans supported (max):
- 3
Number of rear fans supported (max):
- 1
Number of side fans supported (max):
- 2
Number of top fans supported (max):
- 3
Rear fans diameters supported:
- 120,140 mm
Rear fans installed:
- 1x 120 mm
Side radiator sizes supported:
- 240 mm
Top fans diameters supported:
- 120,140 mm
Top radiator sizes supported:
- 240,280,360 mm
Design
Anti-dust filter:
- Yes
Form factor:
- Midi Tower
Full-Height expansion slots:
- 7
Illumination:
- Yes
Illumination colour:
- Multi
Illumination location:
- Case fans
Material thickness:
- 0.6 mm
Maximum CPU cooler height:
- 17.5 cm
Maximum graphics card length:
- 40 cm
Maximum PSU length:
- 22 cm
Number of 2.5" bays:
- 3
Number of 3.5" bays:
- 2
Number of 5.25" bays:
- 0
Number of expansion slots:
- 7
Number of internal 3.5" bays:
- 2
Product colour:
- Black
RGB control button:
- Yes
Side window:
- Yes
Supported motherboard form factors:
- ATX, EATX, ITX, micro ATX, Mini-ITX
Tempered glass panel(s):
- Yes
Ergonomics
Cable management:
- Yes
Packaging content
LED controller:
- Yes
Performance
Fan speed control:
- Yes
Reset button:
- Yes
Suitable for:
- Gaming
Ports & interfaces
Audio input:
- Yes
Audio output:
- yes
On/off button:
- Yes
USB 2.0 ports quantity:
- 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
- 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
- 1
USB Type-C ports quantity:
- 1
Power
Power supply included:
- No
Power supply
Power supply location:
- Bottom
Storage
Number of storage drives supported:
- 5
Supported HDD sizes:
- 2.5,3.5\"
Weight & dimensions
Depth:
- 465 mm
Height:
- 495 mm
Package weight:
- 9.5 kg
Weight:
- 8 kg
Width:
- 230 mm
