ASUS PRIME H610M-A-CSM Intel H610 LGA 1700 micro ATX (90MB1G20-M0EAYC)
Χαρακτηριστικά
Κατασκευαστής:
Asus
Motherboard chipset family:
- Intel
Back panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
- 2
Expansion slots
Number of M.2 (M) slots:
- 2
PCI Express x1 (Gen 3.x) slots:
- 1
PCI Express x16 (Gen 4.x) slots:
- 1
Internal I/O
12V power connector:
- Yes
ATX Power connector (24-pin):
- Yes
CPU fan connector:
- Yes
EPS power connector (8-pin):
- Yes
Front panel audio connector:
- Yes
Number of chassis fan connectors:
- 2
Number of COM connectors:
- 1
S/PDIF out connector:
- Yes
TPM connector:
- Yes
USB 2.0 connectors:
- 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
- 1
Lens system
Component for:
- PC
Memory
Maximum internal memory:
- 96 GB
Memory channels:
- Dual-channel
Memory slots type:
- DIMM
Non-ECC:
- Yes
Number of memory slots:
- 2
Supported memory clock speeds:
- 4800,5000,5200,5400,5600 MHz
Supported memory types:
- DDR5-SDRAM
Unbuffered memory:
- Yes
Motherboard
Motherboard form factor:
- micro ATX
Networking
Ethernet LAN:
- Yes
Wi-Fi:
- No
Other features
Ethernet interface type:
- Fast Ethernet, Gigabit Ethernet
Performance
Audio output channels:
- 7.1 channels
BIOS memory size:
- 128 Mbit
BIOS type:
- UEFI AMI
Compatible processor series:
- Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Motherboard chipset:
- Intel H610
Ports & interfaces
DisplayPorts quantity:
- 1
Ethernet LAN (RJ-45) ports:
- 1
HDMI ports quantity:
- 1
Headphone outputs:
- 1
Microphone in:
- Yes
Number of SATA III connectors:
- 4
PS/2 ports quantity:
- 2
USB 2.0 ports quantity:
- 4
VGA (D-Sub) ports quantity:
- 1
Processor
Parallel processing technology support:
- Not supported
Processor manufacturer:
- Intel
Processor socket:
- LGA 1700
Storage
Number of HDDs supported:
- 4
Number of storage drives supported:
- 6
Supported storage drive interfaces:
- M.2, SATA III
Supported storage drive types:
- HDD & SSD
System requirements
Windows operating systems supported:
- Windows 10 x64, Windows 11 x64
Weight & dimensions
Depth:
- 216 mm
Height:
- 39 mm
Package depth:
- 263 mm
Package height:
- 51.5 mm
Package weight:
- 1.07 kg
Package width:
- 270 mm
Weight:
- 554 g
Width:
- 244 mm
