Χαρακτηριστικά
Κατασκευαστής:
Asus
Motherboard chipset family:
- Intel
Back panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
- 4
BIOS
Clear CMOS button:
- Yes
Design
Product colour:
- Black
Expansion slots
Number of M.2 (M) slots:
- 2
PCI Express x16 (Gen 5.x) slots:
- 5
Graphics
On-board graphics card:
- No
Internal I/O
12V power connector:
- Yes
ATX Power connector (24-pin):
- Yes
CPU fan connector:
- Yes
EPS power connector (8-pin):
- Yes
Front panel audio connector:
- Yes
Number of chassis fan connectors:
- 5
Number of COM connectors:
- 1
TPM connector:
- Yes
USB 2.0 connectors:
- 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
- 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors:
- 1
Lens system
Component for:
- Workstation
Memory
ECC:
- Yes
Maximum internal memory:
- 2.05 TB
Memory channels:
- Quad-channel
Memory slots type:
- DIMM
Number of memory slots:
- 8
Supported memory clock speeds:
- 4800,5000,5200,5400,5600,5800,6000,6200,6400,6600,6800 MHz
Supported memory types:
- DDR5-SDRAM
Motherboard
Motherboard form factor:
- SSI CEB
Networking
Ethernet LAN:
- Yes
Wi-Fi:
- No
Other features
Ethernet interface type:
- 2.5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Performance
Audio chip:
- Realtek S1220A
Audio output channels:
- 7.1 channels
BIOS memory size:
- 512 Mbit
BIOS type:
- UEFI AMI
Compatible processor series:
- Intel Xeon W
Motherboard chipset:
- Intel W790
RAID levels:
- 0, 1, 5, 10
Ports & interfaces
Ethernet LAN (RJ-45) ports:
- 2
Headphone outputs:
- 1
Microphone in:
- Yes
Number of SATA III connectors:
- 4
S/PDIF out port:
- Yes
USB 2.0 ports quantity:
- 8
USB 3.2 Gen 2x2 Type-C ports quantity:
- 1
Processor
Intel Xeon series:
- W-3400, W-2400
Processor manufacturer:
- Intel
Processor socket:
- LGA 4677 (Socket E)
Storage
Number of HDDs supported:
- 4
Number of storage drives supported:
- 6
RAID support:
- Yes
Supported storage drive interfaces:
- M.2, SATA III
Supported storage drive types:
- HDD & SSD
System requirements
Windows operating systems supported:
- Windows 10 x64, Windows 11
Weight & dimensions
Depth:
- 277 mm
Height:
- 50 mm
Package depth:
- 312 mm
Package height:
- 108 mm
Package weight:
- 3.52 kg
Package width:
- 370 mm
Weight:
- 1.81 kg
Width:
- 305 mm
