BUSINESS ELEGANCE
The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance and high quality, while aiming to provide users incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency.
Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation and maintain the performance at heavy loads.
M.2 Shield Frozr
Strengthened M.2 thermal solution helps keep M.2 SSD safe and ensures incredible performance.
Heavy Plated VRM Heatsink
The VRM heatsink covers the upper MOS and helps dissipate the heat.
7W/mK Thermal Pad & Additional Choke Pad
High-quality 7W/mK MOSFET thermal pads and additional choke thermal pads ensure stable performance when all cores are runnging at high speed.
Chipset Heatsink
The chipset heatsink is designed to reduce dust and noise and also capable of maintaining high efficiency of PCH.
LIGHTNING GEN 4 PCI-E
MSI lightning Gen 4 PCI-E represents the bandwidth of a x16 interface to 64GB/s that has doubled compared to its previous generation.
REINFORCED, HEAVY SOLDERED CONNECTIONS
MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points and support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor shields the point of contact from electromagnetic interference.
The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance and high quality, while aiming to provide users incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency.
Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation and maintain the performance at heavy loads.
M.2 Shield Frozr
Strengthened M.2 thermal solution helps keep M.2 SSD safe and ensures incredible performance.
Heavy Plated VRM Heatsink
The VRM heatsink covers the upper MOS and helps dissipate the heat.
7W/mK Thermal Pad & Additional Choke Pad
High-quality 7W/mK MOSFET thermal pads and additional choke thermal pads ensure stable performance when all cores are runnging at high speed.
Chipset Heatsink
The chipset heatsink is designed to reduce dust and noise and also capable of maintaining high efficiency of PCH.
LIGHTNING GEN 4 PCI-E
MSI lightning Gen 4 PCI-E represents the bandwidth of a x16 interface to 64GB/s that has doubled compared to its previous generation.
REINFORCED, HEAVY SOLDERED CONNECTIONS
MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points and support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor shields the point of contact from electromagnetic interference.
Χαρακτηριστικά
Κατασκευαστής:
MSI
Motherboard chipset family:
- AMD
PC health monitoring:
- Fan
Back panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
- 4
Expansion slots
Number of M.2 (M) slots:
- 2
PCI Express x16 (Gen 3.x) slots:
- 1
Internal I/O
ATX Power connector (24-pin):
- Yes
Chassis intrusion connector:
- Yes
CPU fan connector:
- Yes
Front panel audio connector:
- Yes
Front panel connector:
- Yes
USB 2.0 connectors:
- 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
- 2
Lens system
Component for:
- PC
Memory
Maximum internal memory:
- 128 GB
Number of memory slots:
- 4
Supported memory clock speeds:
- 4800,5000,5200,5400,5600,5800,6000,6200,6400 MHz
Supported memory types:
- DDR5-SDRAM
Motherboard
Motherboard form factor:
- micro ATX
Networking
Bluetooth version:
- 5.2
Ethernet LAN:
- Yes
LAN controller:
- Realtek RTL8125-BG
Top Wi-Fi standard:
- Wi-Fi 6E (802.11ax)
Wi-Fi:
- Yes
Wi-Fi standards:
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Other features
Ethernet interface type:
- 2.5 Gigabit Ethernet
Performance
Audio chip:
- Realtek ALC897
Audio output channels:
- 7.1 channels
Compatible processor series:
- AMD Ryzen 7 7th Gen, AMD Ryzen 9 7th Gen
Motherboard chipset:
- AMD B650
RAID levels:
- 0, 1, 10
Supported processor sockets:
- Socket AM5
Ports & interfaces
Bluetooth:
- Yes
Ethernet LAN (RJ-45) ports:
- 1
HDMI ports quantity:
- 1
HDMI version:
- 2.1
Headphone outputs:
- 1
Line-in:
- Yes
Microphone in:
- Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
- 4
Processor
Processor manufacturer:
- AMD
Processor socket:
- Socket AM5
Storage
Supported storage drive interfaces:
- M.2, SATA
System requirements
Windows operating systems supported:
- Windows 11 x64
Weight & dimensions
Depth:
- 243.8 mm
Width:
- 243.8 mm
