Περιγραφή
Proven Reliability and Good Efficiency
Specially designed by be quiet! with the price-conscious PC builder in mind: System Power 9 500W CM offers renowned be quiet! performance and quietness and makes it possible to build cost-effective and reliable systems.
Specially designed by be quiet! with the price-conscious PC builder in mind: System Power 9 500W CM offers renowned be quiet! performance and quietness and makes it possible to build cost-effective and reliable systems.
Χαρακτηριστικά
Κατασκευαστής:
be quiet!
Certification:
- CE, CB, TÜV, RCM, CU
Cooling type:
- Active
Certificates
80 PLUS certification:
- 80 PLUS Bronze
Design
Number of fans:
- 1 fan(s)
Product colour:
- Black
Lamps
Total power:
- 500 W
Logistics data
Harmonized System (HS) code:
- 84733020
Master (outer) case gross weight:
- 14 kg
Master (outer) case height:
- 556 mm
Master (outer) case length:
- 215 mm
Master (outer) case width:
- 311 mm
Products per master (outer) case:
- 6 pc(s)
Packaging content
Manual:
- Yes
Screws included:
- Yes
Packaging data
Cables included:
- PCIe, SATA
Package type:
- Box
Performance
ATX version:
- 2.51
Compatible products:
- Intel C6/C7
Fan diameter:
- 12 cm
Noise level (full-load mode, 100%):
- 24.4 dB
Noise level (quiet mode, 50%):
- 11.5 dB
Noise level (silent mode, <30%):
- 9.7 dB
Power protection features:
- Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power supply unit (PSU) form factor:
- ATX
Purpose:
- PC
Ports & interfaces
Cabling type:
- Semi-Modular
CPU power cable length:
- 60 cm
CPU power connector (4+4 pin):
- Yes
Floppy drive power connector:
- 1
Motherboard power cable length:
- 55 cm
Motherboard power connector:
- 20+4 pin ATX
Number of PATA power connectors:
- 2
Number of SATA power connectors:
- 6
PCI Express power cable length:
- 50 cm
PCI Express power connectors (6+2 pin):
- 2
SATA power cable length:
- 550,670 mm
Power
AC input frequency:
- 50 Hz
AC input voltage:
- 200 - 240 V
Combined power (+12V):
- 456 W
Combined power (+3.3V):
- 110 W
Combined power (+5V):
- 110 W
Combined power (+5Vsb):
- 15 W
Combined power (-12V):
- 3.6 W
Efficiency:
- 89%
Hold time:
- 17 ms
Input current:
- 4 A
Max output current (+12V1):
- 24 A
Max output current (+12V2):
- 20 A
Max output current (+3.3V):
- 24 A
Max output current (+5V):
- 15 A
Max output current (+5Vsb):
- 3 A
Max output current (-12V):
- 0.3 A
Power Factor Correction (PFC) type:
- Active
Technical details
Bearing technology:
- Sleeve
Compliance certificates:
- RoHS
Power factor:
- 0.95
Sustainability certificates:
- ENERGY STAR
Weight & dimensions
Depth:
- 140 mm
Height:
- 86 mm
Package depth:
- 268 mm
Package height:
- 195 mm
Package weight:
- 2.22 kg
Package width:
- 97 mm
Weight:
- 1.56 kg
Width:
- 150 mm
