LC-Power LC850P V3.0 power supply unit 850 W 20+4 pin ATX ATX Black (LC850P V3.0)
Χαρακτηριστικά
Κατασκευαστής:
LC-Power
Certification:
- CE, TÜV
Certificates
80 PLUS certification:
- 80 PLUS Platinum
Design
Number of fans:
- 1 fan(s)
Product colour:
- Black
Ergonomics
On/off switch:
- Yes
Internal I/O
EPS power connector (8-pin):
- Yes
Lamps
Total power:
- 850 W
Packaging data
Package type:
- Box
Performance
ATX version:
- 3.0
Fan diameter:
- 13.5 cm
Power protection features:
- Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power supply unit (PSU) form factor:
- ATX
Purpose:
- PC
Ports & interfaces
ATX power connector (20+4 pin):
- Yes
Cabling type:
- Modular
CPU P4 connector (4-pin):
- 1
CPU power cable length:
- 80 cm
Motherboard power cable length:
- 65 cm
Motherboard power connector:
- 20+4 pin ATX
Number of SATA power connectors:
- 10
PCI Express power connectors (12+4 pin):
- 1
PCI Express power connectors (12+4 pin) cable length:
- 600 mm
PCI Express power connectors (6+2 pin):
- 4
Peripheral (Molex) power cable length:
- 350,500,650,800 mm
Peripheral (Molex) power connectors (4-pin):
- 5
SATA power cable length:
- 500,650,800,950 mm
Power
AC input frequency:
- 50/60 Hz
AC input voltage:
- 100 - 240 V
Combined power (+12V):
- 849.6 W
Combined power (+3.3V):
- 100 W
Combined power (+5V):
- 100 W
Combined power (+5Vsb):
- 15 W
Combined power (-12V):
- 4.8 W
Efficiency:
- 92%
Input current:
- 10 A
Max output current (+12V):
- 70.8 A
Max output current (+3.3V):
- 20 A
Max output current (+5V):
- 20 A
Max output current (+5Vsb):
- 3 A
Max output current (-12V):
- 0.4 A
Power Factor Correction (PFC) type:
- Active
Weight & dimensions
Depth:
- 150 mm
Height:
- 86 mm
Package depth:
- 115 mm
Package height:
- 225 mm
Package weight:
- 3.25 kg
Package width:
- 310 mm
Weight:
- 2.92 kg
Width:
- 180 mm
