Χαρακτηριστικά
Κατασκευαστής:
Thermaltake
Certification:
- CE/FCC/UKCA/ICES/LVD/TUV/cTUVus/CB/CCC/BSMI
Certificates
80 PLUS certification:
- 80 PLUS Gold
Design
Number of fans:
- 1 fan(s)
Product colour:
- Black
Lamps
Total power:
- 1050 W
Operational conditions
Operating relative humidity (H-H):
- 5 - 85%
Operating temperature (T-T):
- 0 - 45 °C
Storage relative humidity (H-H):
- 5 - 95%
Storage temperature (T-T):
- -40 - 70 °C
Performance
ATX version:
- 3.0
Fan diameter:
- 12 cm
Mean time between failures (MTBF):
- 100000 h
Power supply unit (PSU) form factor:
- ATX
Purpose:
- PC
Ports & interfaces
Cabling type:
- Fully-Modular
EPS power connector (4+4 pin):
- Yes
Floppy disk drive cable length:
- 15 cm
Floppy disk drive connector:
- Yes
Motherboard power cable length:
- 60 cm
Motherboard power connector:
- 24-pin ATX
Number of SATA power connectors:
- 12
PCI Express power connectors (12+4 pin):
- 1
PCI Express power connectors (12+4 pin) cable length:
- 600 mm
PCI Express power connectors (6+2 pin):
- 5
Peripheral (Molex) power cable length:
- 500,650,800,950 mm
Peripheral (Molex) power connectors (4-pin):
- 4
SATA power cable length:
- 500,650,800,950 mm
Power
AC input frequency:
- 50/60 Hz
AC input voltage:
- 100 - 240 V
Combined power (+12V):
- 1050 W
Combined power (+3.3V):
- 100 W
Combined power (+5V):
- 100 W
Combined power (+5Vsb):
- 15 W
Combined power (-12V):
- 3.6 W
Input current:
- 16 A
Max output current (+12V):
- 87.5 A
Max output current (+3.3V):
- 20 A
Max output current (+5V):
- 20 A
Max output current (+5Vsb):
- 3 A
Power Factor Correction (PFC) type:
- Active
Technical details
Bearing technology:
- FDB
Weight & dimensions
Depth:
- 140 mm
Height:
- 86 mm
Width:
- 150 mm
