Digitus KVM Switch, 2 Port, 4K30Hz, USB-C/USB/HDMI in, HDMI out, Network (DS-12901)
Περιγραφή
New generation KVM switch support USB-C™ notebook computer
It provides USB console, HDMI display, Hub, network and power to USB-C™ notebook computer via 1 USB-C™ cable .
- Use one monitor, mouse and keyboard to operate two computers
- Support 1x USB-C™ notebook computer ( incl. Macbook )
- Provide LAN connection to USB-C™ notebook computer via USB-C™ cable
- Support Power Charging to USB-C™ notebook computer via USB-C™ ( Power adapter is not included)
- Provide 1xUSB3.0 Type C hub to USB-C™ notebook computer
- Support HDMI 4K / 30Hz display
- Integrated USB hub with 2 x USB 2.0 ports for peripheral devices
- KVM powered via USB bus power or external USB-C power input (optional)
- Switching 2 ports via push button or Hotkey
- Plug and Play - no drivers necessary
The DIGITUS® 2-port KVM switch with USB-C™ and network connectivity gives you the ability to control two 4K-capable PCs from a single USB keyboard and mouse. Conveniently switch between the two PCs at the touch of a button, eliminating the need to reconnect all cables. The Gigabit network port provides convenient access to the network via the additional USB-C™ port. The output to a monitor is done via the integrated HDMI output. Audio signals from the microphone and speakers can also be switched. In addition, another USB-C™ port and two USB A (2.0) ports are available on the front, which can be used for further peripherals such as USB sticks or external hard drives. Status LEDs on the front of the switch show you the current status at all times. The slim switch is rounded off by the robust metal housing.
It provides USB console, HDMI display, Hub, network and power to USB-C™ notebook computer via 1 USB-C™ cable .
- Use one monitor, mouse and keyboard to operate two computers
- Support 1x USB-C™ notebook computer ( incl. Macbook )
- Provide LAN connection to USB-C™ notebook computer via USB-C™ cable
- Support Power Charging to USB-C™ notebook computer via USB-C™ ( Power adapter is not included)
- Provide 1xUSB3.0 Type C hub to USB-C™ notebook computer
- Support HDMI 4K / 30Hz display
- Integrated USB hub with 2 x USB 2.0 ports for peripheral devices
- KVM powered via USB bus power or external USB-C power input (optional)
- Switching 2 ports via push button or Hotkey
- Plug and Play - no drivers necessary
The DIGITUS® 2-port KVM switch with USB-C™ and network connectivity gives you the ability to control two 4K-capable PCs from a single USB keyboard and mouse. Conveniently switch between the two PCs at the touch of a button, eliminating the need to reconnect all cables. The Gigabit network port provides convenient access to the network via the additional USB-C™ port. The output to a monitor is done via the integrated HDMI output. Audio signals from the microphone and speakers can also be switched. In addition, another USB-C™ port and two USB A (2.0) ports are available on the front, which can be used for further peripherals such as USB sticks or external hard drives. Status LEDs on the front of the switch show you the current status at all times. The slim switch is rounded off by the robust metal housing.
Χαρακτηριστικά
Κατασκευαστής:
Digitus
Design
Housing material:
- Metal
LED indicators:
- Activity, Status
Product colour:
- Black
Rack mounting:
- N
Display
Built-in display:
- N
HD type:
- 4K Ultra HD
HDCP:
- Y
Logistics data
UK Trade Tariff code:
- 84718000
Networking
Ethernet LAN:
- Y
Operational conditions
Operating relative humidity (H-H):
- 0 - 80%
Operating temperature (T-T):
- 0 - 50 °C
Storage temperature (T-T):
- -20 - 60 °C
Packaging content
Quick installation guide:
- Y
Packaging data
Cables included:
- KVM, USB Type-C
Package volume:
- 2522.52 cm³
Performance
Data transfer rate (max):
- 10.2 Gbit/s
Ports & interfaces
Audio connections:
- Y
Console ports:
- HDMI
Ethernet LAN (RJ-45) ports:
- 1
HDMI ports quantity:
- 2
HDMI version:
- 1.4
Headphone outputs:
- 1
Keyboard port type:
- USB
Mouse port type:
- USB
Number of computers controlled:
- 2
Number of microphone inputs:
- 1
USB 2.0 Type-A hub ports quantity:
- 2
USB 2.0 Type-B ports quantity:
- 1
USB 2.0 Type-C ports quantity:
- 3
USB connector type:
- USB Type-A, USB Type-B, USB Type-C
Video port type:
- USB
Printing
Maximum resolution:
- 3840 x 2160 pixels
Technical details
Country of origin:
- China
Weight & dimensions
Depth:
- 88 mm
Height:
- 26 mm
Package depth:
- 130 mm
Package height:
- 98 mm
Package weight:
- 40 g
Package width:
- 198 mm
Weight:
- 400 g
Width:
- 150 mm
