LevelOne 8-Port Gigabit Switch (GSW-0807)
Περιγραφή
The LevelOne GSW-0807 Gigabit Ethernet Switch is designed for reliable high-performance networking. With its non-blocking switching fabric in full-duplex mode, this switch can deliver up to 2000Mbps per port, while the Store-and-Forward service brings low latency and error-free packet delivery. This highperformance Gigabit Ethernet switch is perfect for fulfilling the demands of online gaming and multimedia streaming. Moreover, this switch also supports IEEE 802.3az Energy Efficient Ethernet which helps reduce power consumption. Power Saving FeaturesThe GSW-0807 supports IEEE 802.3az Energy Efficient Ethernet to provide power-saving benefits without compromising performance. One of the ways it does this is by automatically detecting the length of connected cables and can adjust power usage by saving energy on shorter cable connections. Compact and Stylish DesignThe stylish, compact wall-mountable housing of GSW-0807 fits any working environment. It comeswith 8 10/100/1000Mbps ports to meet SOHO and home network expansion needs. Easy to UseThe GSW-0807 features plug-and-play for easy installation. No configuration is required. Autonegotiation on each port senses the link speed of a network device and adjusts for compatibility and optimal performance.
Χαρακτηριστικά
Κατασκευαστής:
LevelOne
Certification:
- CE, RoHS, FCC
Data transmission
Jumbo frames:
- 9000
Jumbo frames support:
- Yes
MAC address table:
- 8192 entries
Packet forwarding rate (1 Gbps):
- 1488000 pps
Packet forwarding rate (10 Mbps):
- 14880 pps
Packet forwarding rate (100 Mbps):
- 148000 pps
Store-and-forward:
- Yes
Switching capacity:
- 16 Gbit/s
Design
LED indicators:
- Activity, Link, Power
Product colour:
- Black, Red
Rack mounting:
- No
Stackable:
- No
Wall mountable:
- Yes
Logistics data
Harmonized System (HS) code:
- 85176990
Management features
Switch type:
- Unmanaged
Networking
10G support:
- No
Auto MDI/MDI-X:
- Yes
Flow control support:
- Yes
Full duplex:
- Yes
Networking standards:
- IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Operational conditions
Operating relative humidity (H-H):
- 5 - 90%
Operating temperature (T-T):
- 0 - 40 °C
Storage relative humidity (H-H):
- 10 - 90%
Storage temperature (T-T):
- -40 - 70 °C
Packaging content
AC adapter included:
- Yes
Quick start guide:
- Yes
Packaging data
Package type:
- Box
Performance
Auto-negotiation:
- Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity:
- 8
Basic switching RJ-45 Ethernet ports type:
- Gigabit Ethernet (10/100/1000)
Copper ethernet cabling technology:
- 10BASE-T, 100BASE-TX, 1000BASE-T
Gigabit Ethernet (copper) ports quantity:
- 8
Power
Input current:
- 1 A
Power connector:
- DC-in jack
Power consumption (typical):
- 3 W
Power supply included:
- No
Power over Ethernet (PoE)
Power over Ethernet (PoE):
- No
Storage
Flash memory:
- 1024 MB
Technical details
Country of origin:
- China
Weight & dimensions
Depth:
- 89 mm
Height:
- 27 mm
Package depth:
- 92 mm
Package height:
- 92 mm
Package weight:
- 300 g
Package width:
- 142 mm
Weight:
- 135 g
Width:
- 149.5 mm
